Basic parameters
Model Code
MF97
External Dimensions/Color
121mm×277mm×19mm (L×W×T) / Midnight color
Shell Material
aluminium alloy, glass
Display Screen
7 inches IPS Display(capacitive touch screen), 1024×600 pixels
Power Supply Method
DC10V~28V 0.5A, POE Class0
Network connection
Wireless Network, 1000Mbps Ethernet
Total Weight(g)
790
Guidance
voice, light, display screen
Palm vein identification rate(accuracy)
FAR: 0.00001%, FRR: <1%
Language
Chinese
Operation Temperature
-20℃～+65℃
Algorithm Name
HandID
Palm vein identification time
less than 0.8s
Supported IC card type
ISO 14443 Type A
Control Signal
RS485, Wiegand34, ON/OFF signal
The quantity of users(standalone mode)
1,000,000
(1:N comparison, N≦10000)
Identified Objects
Palm vein, Face, IC card
Preservation Temperature
-20℃～+70℃
Operation Humidity
20%RH～80%RH
